ngc 7662: crown of red on the blue snowball

  • Please log in to reply
20 replies to this topic

#1 bill w

bill w

    Voyager 1

  • *****
  • Posts: 10619
  • Joined: 26 Mar 2005
  • Loc: southern california

Posted 14 February 2013 - 12:37 AM

here's NGC 7662, the blue snowball in NII and OIII
in addition to an opposing pair of red fliers
the nebula appears to have a red "crown" (per Sun Kwok's Cosmic Butterflies)

Posted Image

blink

Posted Image

8" LX200R, SX AO, SX H9, .6"/px
astrodon 5nm OIII, 3nm NII
oiii 30x5 min
nii 23x5 min, 16x20 min
11/5-11/10/2012
Los Alamitos, CA Bortle White skies

here's my RGB version from 8/19/06
Posted Image
apologies for different orientation

at a bit of a loss to explain the red around the core
in the RGB. perhaps Ha.
looks like i'll have to try this one with more filters next year ;)

edit: NII long sbus were 20 minutes, not 29

#2 J.P.M

J.P.M

    Gemini

  • *****
  • Posts: 3104
  • Joined: 14 Nov 2006
  • Loc: 65"01'N25"47'E

Posted 14 February 2013 - 06:10 AM

Bill, this is beautiful work! Love those tiny planetaries, they are like space candies.

#3 Leonardo70

Leonardo70

    Apollo

  • -----
  • Posts: 1193
  • Joined: 16 Apr 2009
  • Loc: Turin - Italy

Posted 14 February 2013 - 06:22 AM

Really nice shot..

All the best,
Leo

#4 NorthBoundTrain

NorthBoundTrain

    Mercury-Atlas

  • *****
  • Posts: 2929
  • Joined: 23 Nov 2011

Posted 14 February 2013 - 06:47 AM

Great catch Bill!

#5 vpcirc

vpcirc

    Skylab

  • *----
  • Posts: 4009
  • Joined: 09 Dec 2009
  • Loc: Merced CA

Posted 14 February 2013 - 09:41 AM

Beautiful!!!

#6 schmeah

schmeah

    Apollo

  • -----
  • Posts: 1354
  • Joined: 26 Jul 2005
  • Loc: Morristown, NJ

Posted 14 February 2013 - 09:51 AM

That's great Bill! A lot of NII in there. How did you map the colors/blend in the narrowband data?

Derek

#7 jerryyyyy

jerryyyyy

    Apollo

  • -----
  • Posts: 1278
  • Joined: 06 Oct 2011
  • Loc: Stanford, California

Posted 14 February 2013 - 10:15 AM

Very nice. As a novice to all this, but starting to image larger narrow band targets... have not done well with this tiny object. How come you are using 5' subs and not all longer? I see you also have some 29' ones. Theory?

#8 jaddbd

jaddbd

    Viking 1

  • -----
  • Posts: 877
  • Joined: 18 May 2005
  • Loc: Woodbine, MD

Posted 14 February 2013 - 02:01 PM

Nice!

John D

#9 bill w

bill w

    Voyager 1

  • *****
  • Posts: 10619
  • Joined: 26 Mar 2005
  • Loc: southern california

Posted 14 February 2013 - 02:43 PM

thanks for the kind comments

#10 bill w

bill w

    Voyager 1

  • *****
  • Posts: 10619
  • Joined: 26 Mar 2005
  • Loc: southern california

Posted 14 February 2013 - 02:45 PM

That's great Bill! A lot of NII in there. How did you map the colors/blend in the narrowband data?

Derek

for this one i just did a simple "balanced NOO" (NII = red, OIII = green and blue) for the star field (nebula was all teal). used a slight stretch to lighten the background stars, to match the red stars brought out below.

did a separate narrow band balance pass to bring out the red fliers. don't remember the multiple, but i think it was 4-8x to the NII red channel. this of course turned all the stars red except the saturated central star, hence the first step above. this was a purist linear stretch as i was concentrating on the bright core. followed by a few rounds of RL deconvolution.

#11 bill w

bill w

    Voyager 1

  • *****
  • Posts: 10619
  • Joined: 26 Mar 2005
  • Loc: southern california

Posted 14 February 2013 - 02:54 PM

Very nice. As a novice to all this, but starting to image larger narrow band targets... have not done well with this tiny object. How come you are using 5' subs and not all longer? I see you also have some 29' ones. Theory?

sorry for the typo, longer subs were 20 minutes.

several reasons for short subs:
1. the NII signal is very weak (see response to derek above)
so in order to pick it up i had to go with much longer exposures, and stretch the red data more in order to bring out the red in the color picture (this is a hallmark of narrow band processing). conversely the central OIII signal is quite strong (this is a bright PN!)

since the NII data was relatively weak, due to inherently low signal, not much point to going deeper with OIII as my intent was to portray the two color channels together.

this nebula does have a faint outer OIII shell, so it's not crazy to go with longer exposures too. one of the difficulties with small bright planetaries like this is that this will generate massive diffraction spikes if you have a scope with a spider (reason i don't). and can make for blooms. even my NABG chip will give artifacts (not quite blooms) if you really saturate it. can be processed out in part, but it's a pain.

#12 jshalpha

jshalpha

    Viking 1

  • -----
  • Posts: 614
  • Joined: 30 Apr 2005
  • Loc: SF Bay Area

Posted 14 February 2013 - 07:28 PM

Nicely done Bill.

Jim S.

#13 Rick J

Rick J

    Fly Me to the Moon

  • *****
  • Posts: 5758
  • Joined: 01 Mar 2008
  • Loc: Mantrap Lake, MN

Posted 15 February 2013 - 02:29 AM

Very interesting. You are getting a lot of benefit from that NII filter!

Rick

#14 bill w

bill w

    Voyager 1

  • *****
  • Posts: 10619
  • Joined: 26 Mar 2005
  • Loc: southern california

Posted 15 February 2013 - 03:51 PM

thanks rick and JS
one more with this one
and then time for a new filter ;)

#15 Harel_Boren

Harel_Boren

    Vendor-The Boren-Simon PowerNewt Astrograph

  • -----
  • Vendors
  • Posts: 1192
  • Joined: 15 Mar 2009
  • Loc: Israel

Posted 15 February 2013 - 04:10 PM

Jus beautiful!
Cheers,
Harel

#16 Bill Snyder

Bill Snyder

    Apollo

  • -----
  • Posts: 1198
  • Joined: 17 May 2009
  • Loc: Pennsylvania. USA

Posted 15 February 2013 - 11:32 PM

Nice image Bill! This will get added to my list:-) What exposures times did you use for your RGB?
Thanks
Bill

#17 Andreas72

Andreas72

    Explorer 1

  • -----
  • Posts: 93
  • Joined: 17 Sep 2009
  • Loc: Piraeus-Greece

Posted 16 February 2013 - 08:20 AM

Great work Bill!!Congrats.

#18 mcarroll

mcarroll

    Apollo

  • -----
  • Posts: 1029
  • Joined: 28 Aug 2010
  • Loc: Greensboro, NC

Posted 16 February 2013 - 09:59 AM

Nice work Bill!

#19 JohnW*

JohnW*

    Vostok 1

  • -----
  • Posts: 127
  • Joined: 23 May 2009
  • Loc: Phoenix,AZ

Posted 16 February 2013 - 02:50 PM

Impressive. I am always amazed at long focal length shots like these. Great inspiration for us new guys.

#20 bill w

bill w

    Voyager 1

  • *****
  • Posts: 10619
  • Joined: 26 Mar 2005
  • Loc: southern california

Posted 16 February 2013 - 07:27 PM

thanks for the comments RGB subs were very short as it's so bright:
nexstar 8 GPS at ~f10, SX-AO, IDAS LPR, H9C
10x60 sec 8/19/06 los alamitos, CA

#21 Bill Snyder

Bill Snyder

    Apollo

  • -----
  • Posts: 1198
  • Joined: 17 May 2009
  • Loc: Pennsylvania. USA

Posted 16 February 2013 - 07:41 PM

Thanks Bill! Alot of these little planetaries are very bright. This will save me some trial and error time:-)
Bill
