Buhlig
super member
Reged: 12/03/07
Posts: 192
Loc: Derby, KS
|
|
I've seen many rave about Adobe Photoshop, but I'm still on the fence considering a purchase. Anyone care to take a stab at processing my latest M33? I'd like to see how much a difference it makes. The full size .jpg is here
Thanks,
Sean
--------------------
Celestron 80mm ED Apochromatic Refractor
Orion 8" Newt
Celestron 80ST achro (guider)
PHD via handcontroller interface
CG-5 Advanced GT Mount
Canon 350D
Philips SPC900NC
http://www.flickr.com/photos/derbysluggers/sets/72157605255114566/
|
Rankinstudio
sage
Reged: 04/05/08
Posts: 411
Loc: Salt Lake City, UT, Lake Powel...
|
|
Be better if you uploaded the .tiff
1 minute adjustment in photoshop
Ran it through Gradient X Terminator
Curves Adjustment
Color Balance
--------------------
David Rankin
http://www.rankinstudio.com
Astro Gallery
Orion 254mm F4.7 (imaging scope)
Baader MPCC
Quickcam pro 9000 (guider, imager)
Canon Rebel XSi (self modified)
Atlas EQ-G (EQ MOD)
Canon 50mm F1.8 II Lens
Canon 28-200 F3.2 Lens
DSLR peltier cooler
|
Nils_Lars
Post Laureate
Reged: 01/04/08
Posts: 3395
Loc: Santa Cruz Mountains , CA
|
|
Ya we need a crack at the Tiff Stack to really do it justice but I have seen people do great things with Photoshop or Iris or Pixinsight along with other programs I think it just depends on the difficulty level and how much you want to spend.
--------------------
Erik
Orion Atlas Self Hypertuned (EQMOD)
Orion ED 80
Williams Optics VII reducer
Celestron 8" SCT
Orion Starshoot Autoguider
PHD guide
Canon 400D Hap Griffin Mod w/Baader filter
Astronomik clip-in LP filter and 12nm Ha
Stilleto CVF and Bahtinov mask
Tamron 75-300mm&28-80mm lenses
NexImage webcam
http://www.flickr.com/photos/31986095@N05/
|
Buhlig
super member
Reged: 12/03/07
Posts: 192
Loc: Derby, KS
|
|
a'right...I'll post the .tiff tonight. It doesn't seem quite "red" enough, but I definitely like the gradient reduction. Looks like it lost a little detail, hard to tell from the small size. Do you guys want a raw stack out of neb? That is, unstretched full spectrum?
FWIW, I've tried IRIS and had a really difficult time with the stretch in IRIS (asinh)...finally just gave up. The registration is nice in IRIS though. Neb seems to have a much finer means of stretching and scaling...but I could be just missing the IRIS boat I suppose.
Sean
--------------------
Celestron 80mm ED Apochromatic Refractor
Orion 8" Newt
Celestron 80ST achro (guider)
PHD via handcontroller interface
CG-5 Advanced GT Mount
Canon 350D
Philips SPC900NC
http://www.flickr.com/photos/derbysluggers/sets/72157605255114566/
|
Ion01
member
Reged: 01/25/08
Posts: 47
|
|
Here is one with a little work on the JPG. I am sure we could get a ton more with the tiff as you obviously picked up a lot of information in your image! This is an incredible shot!
|
Buhlig
super member
Reged: 12/03/07
Posts: 192
Loc: Derby, KS
|
|
apparently, flickr converts .tiff uploads to .jpg, urrggh!...how can I get you guys the .tiff file?
Sean
--------------------
Celestron 80mm ED Apochromatic Refractor
Orion 8" Newt
Celestron 80ST achro (guider)
PHD via handcontroller interface
CG-5 Advanced GT Mount
Canon 350D
Philips SPC900NC
http://www.flickr.com/photos/derbysluggers/sets/72157605255114566/
|
Samir Kharusi
scholastic sledgehammer
Reged: 06/14/05
Posts: 983
Loc: Oman
|
|
Transfer big files
--------------------
Bored? Peruse my website:
http://www.samirkharusi.net/
|
Psyire
scholastic sledgehammer
Reged: 06/24/07
Posts: 978
Loc: 55* North
|
|
Make sure the .tif is just a stacked version, not one that has been post processed with an image editor. (that will make a difference too)
--------------------
Celestron CPC 1100 XLT, Sky-Watcher Equinox 80ED
TV 31T5-Nagler, 8&13mm-Ethos
EarthWin Binoviewers w/ 24mm Panoptics
Elusive Photons.com
|
Buhlig
super member
Reged: 12/03/07
Posts: 192
Loc: Derby, KS
|
|
ok...here it is M33HIRES . It is stacked in Neb, nothing else. Darks and flats applied prior to color conversion. Thanks in advance. I very curious to see how it turns out. This is 15x5min subs with a 10" f/5 newt in pretty dark skies. Should have a ton of detail.
Sean
--------------------
Celestron 80mm ED Apochromatic Refractor
Orion 8" Newt
Celestron 80ST achro (guider)
PHD via handcontroller interface
CG-5 Advanced GT Mount
Canon 350D
Philips SPC900NC
http://www.flickr.com/photos/derbysluggers/sets/72157605255114566/
|
John Miranda
member
Reged: 09/13/09
Posts: 41
Loc: Oro Valley, Arizona
|
|
Ion101 - Your adjustments are wonderful.
Would you share the workflow/tools you applied in PS?
--------------------
John Miranda
www.johnmiranda.com
|
Rankinstudio
sage
Reged: 04/05/08
Posts: 411
Loc: Salt Lake City, UT, Lake Powel...
|
|
yea, playing with jpg's doesn't help much. Here is the tiff after I spent about 45 mins on it playing around. I have to compliment you on the capture, it is really good with tons of detail. Was a real pleasure working on it. Hope you like the results...
Full Res
http://www.slas.us/gallery2/main.php?g2_itemId=2651&g2_imageViewsIndex=1
Opened the image, stretched it with curves, did a color balance adj. - used gradient X terminator - another curves adjust - another color adjust - reopened original image - layed it over and made a layer mask to bring back the bright areas - flattened image - increased saturation - pulled out a better exposure balance with the shadows/highlights tool (set final black point) - used Noel Carboni's "Deep space noise reduction" & "color blotch reduction" saved it out
--------------------
David Rankin
http://www.rankinstudio.com
Astro Gallery
Orion 254mm F4.7 (imaging scope)
Baader MPCC
Quickcam pro 9000 (guider, imager)
Canon Rebel XSi (self modified)
Atlas EQ-G (EQ MOD)
Canon 50mm F1.8 II Lens
Canon 28-200 F3.2 Lens
DSLR peltier cooler
Edited by Rankinstudio (10/23/09 02:08 PM)
|
Nils_Lars
Post Laureate
Reged: 01/04/08
Posts: 3395
Loc: Santa Cruz Mountains , CA
|
|
You have some super data here Buhlig its wasnt hard to get it look good and I could have done a few simple tweaks and been happy but I kind of went as far as I could just to see what I could get out of using Photoshop.
I guess I went a little bluer then David did but thats easy enough to fix , its all personal taste.
I kind did my standard routine of a run through Nebulosity for the DDP which was a little darker then my subs come out but I usually stack in DSS.
First ran a couple more curves and then I set black points in levels in each channel.
I ran GradX like they recommend on there web site and croped it down a bit.
Then reset black points again in each channel and then using curves and ctrl click on the darkest points and brightest points and then using arrow keys to adjust I was able to pull some detail up.
I did a high pass filter layer to sharpen then did a inverse mask as shown on the light buckets site with noise ninja and a color boost with match color.
--------------------
Erik
Orion Atlas Self Hypertuned (EQMOD)
Orion ED 80
Williams Optics VII reducer
Celestron 8" SCT
Orion Starshoot Autoguider
PHD guide
Canon 400D Hap Griffin Mod w/Baader filter
Astronomik clip-in LP filter and 12nm Ha
Stilleto CVF and Bahtinov mask
Tamron 75-300mm&28-80mm lenses
NexImage webcam
http://www.flickr.com/photos/31986095@N05/
Edited by Nils_Lars (10/23/09 12:55 AM)
|
justabob
Carpal Tunnel
Reged: 05/05/07
Posts: 1676
|
|
Great data!
cs3
--------------------
http://www.pbase.com/rkn/astro&page=all
Vixen Sphinx SXW
Meade sn6
Canon EF 200mm f/2.8L II USM Lens
Hutech 1000d
Self modded 350d
ST8300c on order
DSI PRO II
Bob
|
Psyire
scholastic sledgehammer
Reged: 06/24/07
Posts: 978
Loc: 55* North
|
|
Amazing Data! I spent about an hour on this process and had a lot of fun, thanks! 100% Photoshop...
Click for Higher Resolution:
--------------------
Celestron CPC 1100 XLT, Sky-Watcher Equinox 80ED
TV 31T5-Nagler, 8&13mm-Ethos
EarthWin Binoviewers w/ 24mm Panoptics
Elusive Photons.com
|
Samir Kharusi
scholastic sledgehammer
Reged: 06/14/05
Posts: 983
Loc: Oman
|
|
Folks, I am most impressed by both the capture quality and the processed examples.
--------------------
Bored? Peruse my website:
http://www.samirkharusi.net/
|
jcham21
sage
Reged: 12/02/07
Posts: 358
Loc: Tucson, Arizona
|
|
Here is my version done in PS CS2:
Larger: http://i129.photobucket.com/albums/p218/jcham21/m33_stack1.jpg
Curves
Noels Astronomy Tools
Took about 20 minutes. Very good data.
Thanks,
James
--------------------
James
Canon XTi
Canon EF 200mm f/2.8L II Camera Lens
Celestar 8
Main Astrophotography Gallery
Comet Lulin Gallery
How To Make a 6" F/15 Refractor
|
Brane
super member
Reged: 07/02/06
Posts: 168
Loc: Slovenia, Europe
|
|
Nice data.
High resolution ftp://ftp.hicsalta.si/incoming/astro/m33_stack-3-big.jpg
--------------------
http://www.rezman-obs.si
Edited by Brane (10/23/09 10:25 AM)
|
Agnotio
sage
Reged: 08/29/08
Posts: 228
Loc: Ottawa, Canada
|
|
I really like Nils version, makes me consider getting Nebulosity. Although I think most of the work flow was in Photoshop, the high pass filter especially makes a difference. The only thing was maybe he could have pulled out more of the Ha nebulosity to made it redder.
--------------------
Sky-Watcher Equinox 80ED
EQ6 Pro with EQMOD
Canon 450D
Sky-Watcher 10" f/4.7 Dob
|
xatamec
member
Reged: 09/12/09
Posts: 46
Loc: Catalonia, Spain
|
|
I'll try to convince you that you don't need PS, but need PixInsight instead. Much cheaper and much more powerful and focussed for astrophotography works. I would have liked to process it from the very beginning though.
Steps:
Gradients elimination with Dynamic Background Extraction
Histogram stretch
Dynamyc range compression with HDRWavelets
Tiny noise reduction with GreyCRestoration
Color saturation with curves
Sergi
--------------------
My telescopes: WO Megrez 88FD APO and SW 200/1000
My mount: SW EQ6
My cameras: Cooled Canon 350D, QHY5
...and very little time to play with these toys!
|
Tonk
Post Laureate
Reged: 08/19/04
Posts: 4350
Loc: Leeds, UK, 54N
|
|
Simple processin - Images Plus DDP, Gradient XT, Iterative curves stretch, LCE, NR, Colour sat
--------------------
Televue 85, GM-8/Gemini, Canon 40D (unmodded), Canon 450D (modded w/Astronomiks clip-ins - UV/IR, OWB)
Coronado SM60/BF10, Baader Herschel Wedge
Leeds Sky Clock Ripon Sky Clock
|
