Crescent Nebula and surrounding structures - Tak 106, 6200MM, Chroma, 25 hours

  • Please log in to reply
4 replies to this topic

#1 HTT

HTT

    Vostok 1

  • *****
  • topic starter
  • Posts: 134
  • Joined: 16 Oct 2008
  • Loc: USA

Posted 22 June 2025 - 02:52 PM

Rain is out of here and I finally got to complete my run on Cresent and friends!



Full details of shot are here: https://ozarkhillsob...res-wide-field/



Half-res image here: https://ozarkhillsob...61922310583.jpg



Date: June 1st - 20th, 2025
Location: Strafford, Missouri USA
Telescope: Takahashi FSQ-106EDX4 with 0.7X 645 Reducer (380 mm)
Mount: ZWO AM5 harmonic drive
Camera: ZWO 6200 MM (monochrome), Temp= -20, Gain= 300 / Chroma RGB + SHO 3nm filters


Guide Scope: Williams Optics 50mm


Guider: ZWO ASI 174 mini


Controller: ZWO ASI Air




Narrowband Acquisition

Sulfer II: 65 frames at 300s = 6.25 hours


Hydrogen Alpha: 65 frames at 300s = 6.25 hours


Oxygen III: 65 frames at 300s = 6.25 hours





Broadband Acquisition

Red: 12 frames at 180s each = 1 hour


Blue: 12 frames at 180s each = 1 hour


Green: 12 frames at 180s each = 1 hour
Luminance: 55 frames at 300s each = 4.5 hours



Total acquisition time = 26.25 hours




Darks/Flats/Bias: (None)
Processing: Pixinsight, Photoshop


Bortle Class Sky: 3-4





  • rwstanley, Joe F Gafford, psandelle and 3 others like this

#2 Dan Crowson

Dan Crowson

    Skylab

  • *****
  • Moderators
  • Posts: 4,091
  • Joined: 08 Oct 2010
  • Loc: Dardenne Prairie, MO

Posted 22 June 2025 - 02:59 PM

Looks very good and a faint hint of the soap bubble as well.



#3 HTT

HTT

    Vostok 1

  • *****
  • topic starter
  • Posts: 134
  • Joined: 16 Oct 2008
  • Loc: USA

Posted 22 June 2025 - 03:19 PM

Thank you! And yes—the Soap Bubble is in there, and it actually stands out more clearly in the OIII channel. Wide fields with those Chroma filters get really interesting once everything’s stacked—there’s such a rich range of subtle color variations. You can definitely catch a hint of it in the final image though.






#4 Greg M

Greg M

    Viking 1

  • *****
  • Posts: 689
  • Joined: 03 Sep 2007
  • Loc: Henderson, NV

Posted 23 June 2025 - 08:57 PM

I'm not seeing the Soap Bubble in your finished image but it's clearly there in that individual sub.

I've just started imaging the Crescent & Soap Bubble myself with only 4.5 hrs of Ha & OIII total from my Bortle 8-9 backyard and I can clearly see it in my data. Also using Chroma 3nm filters.

https://www.nevadade...lae/i-xjZd2bj/A



#5 HTT

HTT

    Vostok 1

  • *****
  • topic starter
  • Posts: 134
  • Joined: 16 Oct 2008
  • Loc: USA

Posted 23 June 2025 - 10:25 PM

The Soap Bubble Nebula (PN G75.5+1.7) is an exceptionally faint planetary nebula. Because of its extremely low surface brightness, detection improves significantly with increased aperture—more photons mean more detail in the faintest structures. In this context, a 152mm apochromatic refractor will naturally outperform a 106mm refractor like my FSQ-106, especially when using narrowband filters such as [O III], which captures the dominant emission from this nebula.



That said, I’m attaching a comparison of your image with mine, not to critique contrast—since the larger 152mm aperture will naturally show finer structure when zoomed in—but to highlight a few stylistic and processing choices that affect how the nebula appears.



A key factor is how emission lines are mapped to color channels in my image. The Soap Bubble emits almost exclusively in the [O III] line at 500.7 nm, with minimal H-alpha and virtually no [S II] signal. Therefore, color assignment during post-processing has a direct impact on the nebula’s visibility.



Personally, I tend to favor a naturalistic palette when possible, aligning emission wavelengths with their visual spectrum counterparts:



[S II] → Red
H-alpha → Green
[O III] → Blue

From what I see in your version, [O III] appears correctly mapped to blue, but H-alpha and [S II] may both be contributing to the red channel. While this can create a pleasing aesthetic for richer emission regions, it may increase the Soap Bubble’s prominence since its signal is confined almost entirely to [O III] but there is no green hue mapping?



I'm not entirely sure but I do witness, with my color assignement anyway - that when I add in the full spectrum the soap bubble blends more into the background.



Also, I tend to preserve the star field in and around most of my images. While it adds complexity to processing, I feel the stars tell a story—anchoring the scene and providing both scale and context. In my humble opinion, they’re as much a part of the narrative as the nebula itself.





  • Joe F Gafford and Caddman like this
